Footprint Expert Pro - Tens of Millions of FREE PARTS

The free Pro was discontinued as of November 1, 2023.
To keep using the Footprint Expert, download the free Calculator, or upgrade to the full version for as little as $149/year.
Download the Calculator or upgrade.

FREE Footprint Expert Evaluation


Compliant with industry standards:
     - IPC-7352 & IPC-7351 - compliant mathematical calculations
     - IPC J-STD-001 - compliant solder joint goals
     - IEC 61188-7 - compliant default zero component orientation

  1. Free training and technical support - Contact Us
  2. Outputs also include: 3D STEP, Allegro, Altium Designer, Altium Nexus, Board Station, CADint, CADSTAR, CircuitStudio,
         CR5000, CR8000, DipTrace, eCADSTAR, OrCAD PCB, P-CAD, PADS / Siemens, Proteus, Xpedition, Design Spark, EAGLE, KiCad, McCAD, Pantheon, Pulsonix, Solo PCB, and TARGET 3001! -- the full edition supports 3D STEP model export directly from package dimensions - User control of Body, Lead and Polarity Color assignments, PTH Lead Length, Y & Z Vertical Axis, Least, Nominal and Maximum Material Condition, Low & High Quality, and 180 different component families!
  3. 44 major Surface Mount component families and 71 sub-families = 115 total families
  4. 26 major Through-hole component families and 39 sub-families = 65 total families
  5. Settings for Mfr. Recommended Footprint patterns
  6. Print preview available
  7. Add 8 different Polarity Marking shapes for Silkscreen Legend and Assembly Top & Bottom layers
  8. Add Keep-outs for Top. Bottom or All Layers for Placement & Height, Trace, Copper, Via, Test Point and round, rectangle, square or map to courtyard shapes, any size and location
  9. Turn Layers on/off to display any layer to the top
  10. Footprint features for Panning, Zoom in & out, Mirror, Rotate
  11. Tools for PADS to CAD, Convert units, Pad Stack and Hole Size Calculator and Axial Lead Form Calculator
