No 3D STEP Polarity Marker on SOT23 Packages
 Post Reply Post Reply
Author
Message
  Topic Search Topic Search  Topic Options Topic Options
Todd Manning View Drop Down
Active User
Active User


Joined: 25 Jul 2013
Location: Perth WA
Status: Offline
Points: 49 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Todd Manning Quote  Post ReplyReply Direct Link To This Post Topic: No 3D STEP Polarity Marker on SOT23 Packages
    Posted: 14 Jun 2018 at 11:41pm
Hi,

When I create a footprint for a SOT23 package there is no pin 1 indicator on the 3D model. The pin 1 indicator on the silkscreen and assembly drawing appear, but that is it.



Thanks
Todd
Back to Top
Back to Top
Tom H View Drop Down
Admin Group
Admin Group
Avatar

Joined: 05 Jan 2012
Location: San Diego, CA
Status: Offline
Points: 5718 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Tom H Quote  Post ReplyReply Direct Link To This Post Posted: 15 Jun 2018 at 6:43am
Component manufacturers do not put Polarity Marking on SOT23 packages.

There are currently 3 pin pitches for SOT23 type packages -
  1. 0.95 mm
  2. 0.65 mm
  3. 0.50 mm
Send us a picture of a SOT23 physical package with a polarity marker.

You can Google search SOT23 Packages and you will not see any Polarity Marking.
Stay connected - follow us! X - LinkedIn
