RJ45 footprint

 Post Reply Post Reply
Author
Message
loic-7 View Drop Down
New User
New User


Joined: 27 Dec 2013
Status: Offline
Points: 3
Post Options Post Options   Thanks (0) Thanks(0)   Quote loic-7 Quote  Post ReplyReply Direct Link To This Post Topic: RJ45 footprint
    Posted: 06 Jan 2014 at 7:47am
Hello everyone,
I need to find the footprints of a RJ45 connector. It's a te connectivity connector.
Here, you can find the reference : http://www.te.com/catalog/pn/en/5520259-4.

I'm a beginner in Allegro PCB Designer, so I will take all of your advices.
Thanks.
Back to Top
Nick B View Drop Down
Admin Group
Admin Group


Joined: 02 Jan 2012
Status: Offline
Points: 1897
Post Options Post Options   Thanks (1) Thanks(1)   Quote Nick B Quote  Post ReplyReply Direct Link To This Post Posted: 06 Jan 2014 at 9:55am

The Library Expert can build this using the Footprint Designer module.

Stay connected - follow us! X - LinkedIn
Back to Top
Tom H View Drop Down
Admin Group
Admin Group
Avatar

Joined: 05 Jan 2012
Location: San Diego, CA
Status: Offline
Points: 5668
Post Options Post Options   Thanks (1) Thanks(1)   Quote Tom H Quote  Post ReplyReply Direct Link To This Post Posted: 06 Jan 2014 at 12:55pm

Using "Footprint Designer", you can easily create this phone jack using 2 pad stacks.

The Parts on Demand (POD) website will soon be on-line starting with over 225,000 Part Numbers and we're adding new parts as fast as we can. This TE Connectivity Footprint only needs to be created once by someone and then upload the FPX file to POD to share it with the entire electronics industry. One person has to build it right and no one will ever have to build it again. Library Expert currently supports 20 different CAD tool interfaces.

Stay connected - follow us! X - LinkedIn
Back to Top
loic-7 View Drop Down
New User
New User


Joined: 27 Dec 2013
Status: Offline
Points: 3
Post Options Post Options   Thanks (0) Thanks(0)   Quote loic-7 Quote  Post ReplyReply Direct Link To This Post Posted: 07 Jan 2014 at 9:22am
Hello,
thank you for your answers. I followed the tutorial "How to design a RJ45 connector", it allowed me to design the connector's footprint and save it in a new library.
The library's extension is .fpx. How can I import this library in Orcad ?
The extension in Orcad for the footprints are .psm and .dra, how can I attach my new footprint to my component in my schematic.
Thanks for your replies.



Back to Top
Nick B View Drop Down
Admin Group
Admin Group


Joined: 02 Jan 2012
Status: Offline
Points: 1897
Post Options Post Options   Thanks (0) Thanks(0)   Quote Nick B Quote  Post ReplyReply Direct Link To This Post Posted: 07 Jan 2014 at 9:34am
