rdl86626
Advanced User Joined: 20 Jul 2012 Location: Hollister, CA Status: Offline Points: 83 |
Post Options
Thanks(0)
Posted: 17 Sep 2012 at 11:39am |
Tom or anyone, When I tried to create a rectangular padstack in padstack designer I could only get square. Every time I click on the rectangle it ould pop up square. Any help? |
|
Jeff.M
Admin Group Joined: 16 May 2012 Location: San Diego Status: Offline Points: 477 |
Post Options
Thanks(1)
|
Actually, the pad stack designer, though functional doesn't currently contribute to any footprint generator process and really should be turned off. It was used primarily a tool for developing the pad stack software.
However, since you asked...notice the Height & Width controls below the Shape selection pull down menu. If you change width to be longer than height or height to be less than width you'll get the rectangle shape.
|
|
rdl86626
Advanced User Joined: 20 Jul 2012 Location: Hollister, CA Status: Offline Points: 83 |
Post Options
Thanks(0)
|
So you can not edit a padstack in this tool, only in the board software?
|
|
Tom H
Admin Group Joined: 05 Jan 2012 Location: San Diego, CA Status: Offline Points: 5716 |
Post Options
Thanks(1)
|
That's correct for V2012.
We will add many new interactive advanced features in the V2013 release. |
|
Maarten Verhage
Active User Joined: 27 Jul 2012 Location: Netherlands Status: Offline Points: 27 |
Post Options
Thanks(0)
|
I hope you could complete the padstack manager so it will generate a perfect solder paste layer. All with rounded corners, percentage reductions etcetera. Then I can ask the assembly facility that no adjustments have to be made to that layer.
Success to the software developers! Best regards, Maarten |
|
Tom H
Admin Group Joined: 05 Jan 2012 Location: San Diego, CA Status: Offline Points: 5716 |
Post Options
Thanks(0)
|
Adding a Paste Mask reduction by percentage is high on our list on new features for V2012.
But our first goal is to complete the standard Through-hole component families. I believe the answer to the first question in this thread has been answered - Yes PCB Footprint Expert for Rounded Rectangle pad shape now works in Allegro. |
|
