Footprint for TO-220 Vertical

Message Topic Search Topic Options Post Reply Create New Topic Printable Version Translate Topic

   I try to create the footprint forhttps://www.onsemi.com/pub/Collateral/TIP50-D.pdf
The datasheet doesn't content any recommendation.
If i create it in calculator than the pads cover each other
partially. I want to redraw the pad dimension manually.
Is there any general recommendations to create the elongate pad?

Author	Message Topic Search Topic Options Post Reply Create New Topic Printable Version Translate Topic
Batiskaff Members Profile Send Private Message Find Members Posts Add to Buddy List Advanced User Joined: 30 Apr 2018 Status: Offline Points: 65	Post Options Post Reply Quote Batiskaff Report Post Thanks(0) Quote Reply Topic: Footprint for TO-220 Vertical Posted: 27 Feb 2020 at 10:55pm
	I try to create the footprint for https://www.onsemi.com/pub/Collateral/TIP50-D.pdf The datasheet doesn't content any recommendation. If i create it in calculator than the pads cover each other partially. I want to redraw the pad dimension manually. Is there any general recommendations to create the elongate pad?



Tom H Members Profile Send Private Message Find Members Posts Add to Buddy List Admin Group Joined: 05 Jan 2012 Location: San Diego, CA Status: Offline Points: 5774	Post Options Post Reply Quote Tom H Report Post Thanks(0) Quote Reply Posted: 28 Feb 2020 at 8:23am
	The Pin Pitch is 2.54 mm (100 mil). The pads should not overlap.
	Stay connected - follow us! X - LinkedIn

Batiskaff Members Profile Send Private Message Find Members Posts Add to Buddy List Advanced User Joined: 30 Apr 2018 Status: Offline Points: 65	Post Options Post Reply Quote Batiskaff Report Post Thanks(0) Quote Reply Posted: 28 Feb 2020 at 9:18am
	I am sorry, the right datasheet is here: http://ww1.microchip.com/downloads/en/DeviceDoc/21374D.pdf see page 11.

Tom H Members Profile Send Private Message Find Members Posts Add to Buddy List Admin Group Joined: 05 Jan 2012 Location: San Diego, CA Status: Offline Points: 5774	Post Options Post Reply Quote Tom H Report Post Thanks(0) Quote Reply Posted: 28 Feb 2020 at 9:32am
	Then you make the "D" and "D1" dimensions different. You must bend the leads. You decide the dimension value that you want to bend 2 leads.
	Stay connected - follow us! X - LinkedIn

Batiskaff Members Profile Send Private Message Find Members Posts Add to Buddy List Advanced User Joined: 30 Apr 2018 Status: Offline Points: 65	Post Options Post Reply Quote Batiskaff Report Post Thanks(0) Quote Reply Posted: 28 Feb 2020 at 11:33am
	As i understand, constrict + stretch the pads is undesirable. For example, footprint on page 15: http://www.ti.com/lit/gpn/UC385?keyMatch=kc0005a&tisearch=Search-EN-Keyword

Tom H Members Profile Send Private Message Find Members Posts Add to Buddy List Admin Group Joined: 05 Jan 2012 Location: San Diego, CA Status: Offline Points: 5774	Post Options Post Reply Quote Tom H Report Post Thanks(0) Quote Reply Posted: 28 Feb 2020 at 11:55am
	Do you want the oblong pad version? I'll build it for you. Simple 5-minute task in FP Designer.
