Can anyone share details of BGA pad, via, trace width , Clearance of 0.4 mm pitch BGA
|
|
 |
|
|
|
|
Tom H
Admin Group
Joined: 05 Jan 2012 Location: San Diego, CA Status: Offline Points: 5717 |
Post Options
Thanks(0)
Quote Reply
Posted: 07 Feb 2017 at 9:35am |
|
It depends on how many Rows and Columns the BGA has.
|
|
|
|
|
mahmoodv99
Advanced User
Joined: 16 Jan 2016 Status: Offline Points: 93 |
Post Options
Thanks(0)
Quote Reply
Posted: 07 Feb 2017 at 8:31pm |
|
This is my part: CYW4339XKUBG
Any pdf documents is available ?
|
|
|
|
|
Tom H
Admin Group
Joined: 05 Jan 2012 Location: San Diego, CA Status: Offline Points: 5717 |
Post Options
Thanks(0)
Quote Reply
Posted: 08 Feb 2017 at 7:53am |
|
Here is the Cypress/Broadcom datasheet link - http://www.cypress.com/file/298016/download
This is a very nice BGA. If you get the X/Y coordinates for the pads, I will build the library part for free.  |
|
|
|
|
